Orifice Flanges

While orifice flange share similarities with standard pipe flange, they come in different configurations to suit various piping requirements. Texas Flange offers:

For larger sizes exceeding 24 inches, Texas Flange supplies orifice flange manufactured to the MSS SP-44 standard, ensuring superior performance even in the most demanding environments.

Pressure Taps: Our orifice flange come with machined pressure tap holes, simplifying installation and delivering accurate pressure readings without additional pipe tappings.

Jack Screws: Orifice flange include jack screws for easy removal during installation, inspection, and maintenance tasks. It helps quickly remove flange to replace orifice plates and gaskets.

Precision Orifice Plate: The key element of the system that causes a pressure drop proportional to the flow rate is the orifice plate, which has a carefully measured opening. Texas Flange ensures that every orifice plate is tailored for precision and dependability according to unique service conditions.

High-Performance Gaskets: Orifice flange available with a spiral wound or RTJ gaskets with raised face or RTJ face for secure seals.

Orifice flange are used in multiple industries that need to measure flow accurately.

Oil and gas: In the oil and gas industry, the flow of crude oil, natural gas, and petroleum products is measured.

Chemical processing:  Chemicals are controlled to ensure accurate measurement and quality control.

Power generation: In power generation plants, gauge the flow of steam, water, and fluids to enhance efficiency.

Water treatment:  In water treatment plants for measuring water flow and wastewater for correct treatment.

Food and beverage: In food and beverage processing, oversee the flow of components for consistent quality.

Pharmaceutical:  In pharmaceutical manufacturing, the flow of pharmaceutical substances is monitored for precision and safety.

At Texas Flange, we understand that each application has unique requirements. That's why we offer orifice flange in a variety of materials, including:

Various sizes and pressure ratings of orifice flange, ranging from 300 to 2500, are offered to cater to multiple pipe diameters and industrial applications. All products comply with ASME B16.36 and MSS SP-44 requirements to ensure superior quality and reliability. Texas Flange offers top-quality solutions for accurate flow measurement if your project is in oil and gas, chemical processing, or another high-stakes industry.

Accurate Flow Measurement: We design our orifice flange for precision, optimizing pressure tap locations and configurations to ensure precise pressure differential readings.

Easy Installation and Maintenance: The integrated pressure taps and jack screws make installation and maintenance faster and more straightforward, reducing downtime.

Cost-Effectiveness: Texas Flange provides cost-effective orifice flange with standard sizes to reduce costs for installation and maintenance in the long run.

Versatility Across Industries: We create our products to work effectively across various settings and sectors, from high-pressure steam applications to corrosive chemical environments.
